Mitutoyo 293-130-10 MDH 0.0001mm Digimatic High-Accuracy Micrometer 0-25mm (0-1″)

Previous Product | Next Product

Product Description

£1,790.00 (ex VAT)

Usually ships in: 2-3 days

Delivery price: £5.99

Micrometer Features:

Range: 0-25mm (0-1″)
Resolution: 0.0001mm (0.000005″)
Accuracy: ± 0.0005mm (0.00002″)
Flatness: 0.0003mm (0.000012″)
Parallelism: 0.0006mm (0.00002″)
Measuring Surface: 3.2mm Diameter
Measuring Force: 7-9N
Electromagnetic induction type BS rotary sensor
Battery Life: 2.4 Years
Data output
Inch-mm conversion
Hold function
Auto Power OFF after 20 min non use
Measuring Spindle: with spindle lock, 6.35mm diameter, spindle pitch 0.635mm
MPN: 293-130-10
Brand: Mitutoyo

This Micrometer enables 0.1 μm resolution measurements and is ideal for customers who need to make highly accurate measurements with a hand-held tool (such as Gauge R & R analysis).
The Absolute High-Accuracy Micrometer offers the following benefits:

It delivers higher accuracy without sacrificing operability, by using Mitutoyo‘s innovative 0.1 μm resolution ABS (absolute) rotary
sensor and high accuracy screw machining technology which
reduces instrumental error to just 0.5 μm.
Its highly rigid frame and high-performance constant-force
mechanism (7-9 N) enable more stable measurement.
