Electronic Fine Reading Digital Dial Indicator EDI-125 | Range 0-12.5mm/0-1/2" | Resolution 0.001mm/0.00005" | Accuracy +/- 0.005mm

Product Description
£129.90 (ex VAT)
Usually ships in: 2-3 days
Delivery price: £12.00
  • Measuring Range 0-12.5mm/0-1/2"
  • Resolution 0.001mm/0.00005"
  • Repeatability 0.001mm/0.00005"
  • Accuracy +- 0.005mm
  • Measuring speed: <0.5m/sec
  • Clear LCD display
  • Extra large 14mm digits
  • Lug back
  • Fitted with ball anvil
  • Anvil thread M2.5mm
  • Stem Diameter 8mm
  • Power 1.5V SR-44 Silver Oxide Cell

This model will auto turn off after 4 minutes of non-use. When the indicator is either manually or automatically turned off, it will display zero when turned on whatever the position of the measuring spindle.
